Geodesic Domes are intertwined with the history of Disorient. Domes covered with video are a signature of Disorient.

A geodesic dome is an almost spherical shell structure based on a network of great circles (geodesics) lying approximately on the surface of a sphere. The geodesics intersect to form triangular elements that have local triangular rigidity and also distribute the stress across the entire structure.[1]

Disorient Dome #1 (5V - 36'diameter - 3/4"EMT)

Acquired August 2001 (Gifted by Leo and The Bass. Fabricated by Jochen TBC)
Cover: white
Struts, hardware and cover stored in Disorient BM container

Notes:
-Cover needs new storage container about 2'x2'x2' -eye 06112012

Dome DOERS 2012.jpgDIMSinDome2013.jpgDisorientDome1BM2002.jpg
BurningMan 2002

Dome 2010- by Joe Che

Disorient Dome #2 "Bok" (4V - 32(?)'diameter - 1 1/2(?)" aluminum conduit)

Acquired August 2004
Gold cover (not in good shape) last seen in NY Dock container in March 2016
Struts of dome stored at Leo's NYC studio

List of struts (measurements are holes center-to-center):
- A - 30x - 45.5"
- B - 30x - 53" (has steeper curve than C, otherwise identical)
- C - 60x - 53"
- D - 72x - 56.25"
- E - 30x - 58.25"
- F - 31x - 53.75"
- G - 40x - 47.75"
- H - 18x - 60"
- (H) - 2x - 38.5"
- J - 2x - 40"
- K - 1x - 39.5"

Leo Dome 2004.jpg BokGlobuleDome2004.jpg
Burning Man 2004, Nevada

Disorient Dome #3 "SleepDep" (3V - 23'8"diameter - 3/4"EMT)

Acquired September 2004 (Gifted by SleepDep)
Cover: orange tarps
Struts stored at Dock.
Shipping volume (struts only, hardware and cover shipped in shared black travel crate): 7 cu/ft

Notes:
20120713 - 5/8 config installed at Warsaw for Disorient presents: COMPRESSOR.
20120709 - John Dingee fabricates more struts. Dome now have enough struts for 5/8 config.
20120610 - Strut count (Eye) A:32 B:49 C:75
20120610 - Enough struts for 3/8 config (installed at Figment 2012), some missing struts to complete 5/8 config.
20120610 - When fabricating more struts, consider making enough to complete 3/4 config.
20120610 - Struts color coding not consistent with Desert Dome diagram used for assembly. Remap to: green=yellow, purple=blue, blue=red
20120610 - Need to purchase hardware (bolts, nuts and washers). Until then, use Dome #4 hardware.

DisorientDome3AssemblyDiagram.jpg DisorientDome3Specs.jpg DisorientDome3Detail.jpg DisorientDome3Struts.jpg


Disorient Dome #4 (4V - 32'diameter - 3/4"EMT)

Acquired October 8, 2010 (Gifted by unknown - probably fabricated by Nicholas Whitaker)
Cover: orange tarps
Struts and hardware stored at Dock

PDF-fall2010-DisorientDome.jpg DisorientDome4CountryClub2012.jpg
Disorient Light at PDF, Delaware - October 10, 2010 - Photo by Red Lite ------ > Disorient COUNTRY CLUB - May 25-28, 2012 - Photo by Nicholas Whitaker

DisorientDome4Hardware.jpg DisorientDome4Struts.jpg 4vdiagram.gif

We need to make more back-up struts for Dome #4
- 4 purple
- 4 blue
